Mercury Electra Max 6G 2TB SSD
2TB Mercury Electra™ MAX 6G
2.5" Serial-ATA 7mm Solid State Drive
Premier SSD for Creative A/V Pros Who Know the Difference. With full 3G/1.5G backwards compatiblity.
High Performance Internal Storage
When the success of your project hinges on the performance of your equipment, you need an SSD with the maximum in capacity and speed - you need the 2TB Electra MAX. It's the professional choice, built for ultra-demanding real-world use with the performance and capacity you can count on.
With real-world sustained speeds of 490/471 MB/s read/write, Electra MAX is built to handle big files of incompressible data in the most demanding production environments.
Mercury Electra MAX features premium-quality tier-1 sync NAND, and a suite of controller technologies designed to maximize performance and longevity:
- Global wear leveling algorithms automatically distribute data evenly and manage program/erase count, maximizing SSD lifespan.
- StaticDataRefresh manages free space, gradually refreshing data across the SSD over time, preventing data corruption.
- Hardware BCH ECC corrects errors up to 66-bit/1KB for superior data retention and drive life.
- Advanced security protocols support 128/256-bit-AES disk encryption.
With exceptional wear-leveling and block management, gold-standard compression and data distribution, best-in-class error correction, intelligent recycling, and requiring no external TRIM support, the 2TB Mercury Electra MAX 6G SSD delivers incredible performance and dependability.
No Risk, No Hassle 30-Day Money Back Guarantee.
For more information on OWC return policies,
Please Note:
This drive is designed for use in Mac and PC systems and is NOT supported or recommended for use in any external drive enclosures.
2.0TB Mercury Electra™ MAX 6G SSD Specifications:
Specifications
Controller
Silicon Motion SM2246EN Series with 7% Over Provisioning firmware set
RAID Controller
JMicron S562
NAND
Tier 1 Major Multi-Level Cell (MLC) High-Performance Sync-NAND Flash
Form Factor
Standard 7mm 2.5"
Interface
SATA 6Gb/s, 3Gb/s & 1.5Gb/s supported, SATA 3.0 Compliant
Capacity1
1920GB useable capacity
Total Flash Memory Components – 2048GB
128GB allocated to real-time data redundancy & error correction
Total Flash Memory Components – 2048GB
128GB allocated to real-time data redundancy & error correction
Formatted Capacity2
1788GiB
RAID Support
Qualified for single drive and multiple drive production workstation RAID 0/1/10/0+1 and SPAN usage.
SMART Attributes
Standard4
Native Command Queuing
up to 32 commands
Manufacturer Model Number
OWCSSD7E6G02T
RoHS Compliant
Yes
Format
Unformatted
Physical
Height (max)
7mm (0.276″)
OWC 7mm – 9.5mm Adapter
1 included (buy additional)
Width (max)
70.06mm (2.758″)
Length (max)
100.12mm (3.941″)
Weight
77 grams +/- 2 grams
0.170 lbs +/- 2.71 oz
0.170 lbs +/- 2.71 oz
Reliability3
Data Reliability
Built-in BCH ECC: Up to 66 bits correctable per 1024 bytes
Security
Chip Based Data Encryption: 256-bit AES-compliant
TRIM Support
No
Nonrecoverable Read Errors
Less than 1 sector per 1016bits read
Warranty
Performance
Sustained
Reads 6Gb/s (up to)
Reads 6Gb/s (up to)
490MB/s
Sustained
Writes 6Gb/s (up to)
Writes 6Gb/s (up to)
471MB/s
Read Incompressible
Data Rate (up to)
Data Rate (up to)
466MB/s
Write Incompressible
Data Rate (up to)
Data Rate (up to)
447MB/s
Random 4K Read
Up to 9,000 IOPS
Random 4K Write
Up to 20,000 IOPS
Read Latency
less than 0.1ms
Write Latency
less than 0.1ms
Power
Active
Less than 2000mW (2.0W) expected maximum draw
Idle
Less than 700mW (0.7W)
Environmental (Operating)
Temperature (°F)
32°F to 158°F
Temperature (°C)
0°C to 70°C
Environmental (Non-Operating)
Temperature (°F)
-40°F to 185°F
Temperature (°C)
-40°C to 85°C
Acoustics
Idle (Typical)
0.0 bels
Seek (Typical)
0.0 bels
SKU: OC-SSD7E6G02S
